Model | SUN800G3-EU-230 | SUN1000G3 -EU-230 | ||
Input Data (DC) | ||||
Recommended input power(STC) | 210-600W | |||
Maximum input DC voltage | 60V | |||
MPPT Voltage Range | 25-55V | |||
Operating DC Voltage Range | 20-60V | |||
Max DC short circuit current | 16A | |||
Max input current | 12.5AX2 | |||
Output Data (AC) | ||||
Rated output Power | 800W | 1000W | ||
Maximum output power | 880W | 1100W | ||
Maximum output Current | 3.8 A | 4.8A | ||
Nominal voltage / range | 230V/ 184-265V | |||
Nominal frequency | 50/60HZ | |||
Extended frequency / range | 45~55Hz/ 55~65Hz | |||
Power factor | >0.99 | |||
Maximum unit per branch | 6 | 5 | ||
Max. allowed altitude operating | < 4000m | |||
Max output fault current | 10A | |||
Max output overcurrent promotion | 3.8A | 4.8A | ||
Efficiency | ||||
C'EC： weighted efficiency | 95% | |||
Peak inverter- efficiency | 96.5% | |||
Static MPPT efficiency | 99% | |||
Night time power consumption | 50mW | |||
Mechanical Data | ||||
Ambient temperature range | -40℃～+65℃ | |||
Dimensions(WXHXD mm) | 212 X 229 X 40 mm (Does not include cable) | |||
Weight (kg) | 3.5 | |||
Cooling | Natural C3onvection - No Fans | |||
Enclosure environmental rating | IP67 | |||
Protective class | Class I | |||
Features | ||||
Compatibility | Compatible with 60.72 cell PV modules | |||
Communication | Power line/ WiFi / Zigbee | |||
Compliance | EN50549,VDE0126,VDE4105,IEC62109,CE,INMETRO | |||
Warranty | 10 Years | |||
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||||
CIF | |||||
L/C | L/C amount above 50.000 usd, we can accept L/C at sight | ||||
Delivery Time | 7~1 Odays after receiving payment for one container | ||||
| Contact Person : | Bin |
|---|
